Description
Coinco Vortex MDB
- Model Vortex
- 6 pin
- KEY FEATURES
- MDB (Multi-Drop Bus) Interface
- Accepts US 5¢, 10¢, 25¢ and $1 coin
- Dispenses US 5¢, 10¢, 25¢ and $1 coin.
- Field-proven validation technology
- Super high-capacity hoppers
- Tilt-out coin hopper for easy loading
- Payout sensors ensure coin delivery
- Programmable coin capacity levels (Float Mode)
- Rugged design withstands harsh environments
- high capacity coin hopper design eliminates pay our reconfiguration
- Coin Hoppers hold up to 125 dollar coins, 200 quarters, 460 dimes and 220 nickels, all within standard footprint
- positive payout detection ensures proper coin delivery
- programmable coin capacity levels maximize vends while minimizing coins in the changer
- Flash programmable microcontroller simplifies upgrades for future feature additions.
- Electronic acceptance of up to 16 different coins adaptable to new coins in the future.
- Input Power Requirements – Minimum 20 VDC RMS (Rectified and optionally filtered) @ 1.8A. Nominal 34 VDC (Rectified and filtered) Maximum 42.5VDC (Ripple voltage upper limit)
- Operating Temperature Range – 0° F to 150° F (-18° C to 65° C)
- Storage Temperature Range – -22°F to 160°F (-30°C to 72°C)
